Max. wheel diameter 750 mm Gear
width 200 mm Max. module 10 Min.
module 1 Min. wheel diameter 30 mm Max. number of teeth 300 Min.
number of teeth 6 Tooth helical angle min/max 0 / 60 °
Min. ram stroke 0 mm Max. ram stroke
225 mm Table diameter 460 mm Table load 0,8 t
No. of strokes 23,5 - 150 Hub/min Table hole 90 mm Total
power requirement 7 kW Weight of the
machine ca. 3,8 t Dimensions of the
machine ca. 2,1 x 1,7 x 2,1 m Accessories Set of change gears
Outboard support |
|
|
|
