TECHNICAL
SPECIFICATION
Slotting height 320 mm
diameter of table 630 mm
slide adjustment 250 mm
stroke cross slide table 510 mm
longitudinal travel of table 650 mm
Distance between the tool and the amount 615 mm
tilt head 0 to 10 °
speed of slide 3 to 38 m/min
longitudinal advances and transverse 2.8 mm / mn
speed 4.5 m/min
|
